Description
| Model | Chain No. | Pitch | Bush Type | Width | Pin diameter | Pin length | Roller diameter | Plate Thickness | Tensile | Weight | |
| Inner | Outer | ||||||||||
| mm | mm | mm | mm | mm | mm | kN | kN | kg/m | |||
| Motorcycle Chain | 520H | 15.875 | Curled | 6.35 | 5.08 | 19.1 | 10.16 | 2.42 | 2.42 | 30.5 | 0.96 |
| 520 | 15.875 | Curled | 6.35 | 5.08 | 17.5 | 10.16 | 2.03 | 2.03 | 26.5 | 0.89 | |
| 630 | 19.05 | Curled | 9.5 | 5.94 | 22.7 | 11.91 | 2.42 | 2.42 | 35 | 1.5 | |
| 530 | 15.875 | Curled | 9.53 | 5.08 | 20.7 | 10.16 | 2.03 | 2.03 | 26.5 | 1.09 | |
| 525 | 15.875 | Curled | 8 | 5.08 | 19.4 | 10.16 | 2.03 | 2.03 | 26.5 | 0.93 | |
| 420 | 12.7 | Curled | 6.35 | 3.96 | 14.7 | 7.77 | 1.5 | 1.5 | 15.6 | 0.55 | |
| 415 | 12.7 | Curled | 4.7 | 3.96 | 13 | 7.77 | 1.5 | 1.5 | 17.7 | 0.5 | |
The sprockets work in tandem with their teeth engaging between the drive chain links. The front sprocket rotates at the same time as the engine’s transmission output shaft, and the teeth pull the drive chain, in turn rotating the driven sprocket as it traverses. This system transfers the power from the engine to the rear wheel, moving the motorcycle forward.
